42D0510 IBM QLogic 8Gb FC Dual-port HBA for IBM System x
Description:
| Manufacturer Part |
42D0510 |
| Cost Central Item |
10026928 |
| Product Description |
QLogic 8Gb FC Dual-port HBA for IBM System x - Host bus adapter - PCI Express x4 - 8Gb Fibre Channel x 2 - for System x3100 M4; x3250 M3; x3250 M4; x3300 M4; x3630 M4; x3650 M4 HD; x36XX M3; x3950 X5 |
| Device Type |
Host bus adapter |
| Form Factor |
Plug-in card |
| Interface (Bus) Type |
PCI Express x4 |
| PCI Specification Revision |
PCIe 1.0a, PCIe 1.0 |
| Bus Voltage |
Universal (3.3 V & 5.0 V) |
| Ports |
8Gb Fibre Channel x 2 |
| Approximate Dimensions (WxDxH) |
1 in x 6.6 in x 2.6 in |
| Approximate Weight |
4 oz |
| Data Link Protocol |
8Gb Fibre Channel |
| Data Transfer Rate |
8.5 Gbps |
| RAM |
1 MB |
| Manufacturer Warranty |
1 year warranty |
| Designed For |
System Storage DS3400; System x3100 M4; x3200 M2; x3250 M2; x3250 M3; x3250 M4; x3300 M4; x3350; x3400; x3450; x3500; x3550; x3550 M2; x3620 M3; x3630 M3; x3630 M4; x3650; x3650 M2; x3650 M3; x3650 M4 HD; x3655; x3755; x3850 M2; x3950 M2; x3950 X5 |
